JE Pistons Extreme-Duty 23-Degree Inverted Dome Top Pistons 131631

$675.00

New Old Stock!!!!

Pistons, Forged, Dish, 2-Valve Reliefs, 4.030 in. Bore, 3.750 in. Stroke, 5.700 in. Rod, 1.425 in. Compression, Chevy, Set of 8

Brand: JE Pistons

Manufacturer’s Part Number: 131631

Piston Rings Included: No

Bore (in.): 4.030 in.

Bore (mm): 102.362mm

Stroke: 3.750 in.

Engine Stroke Type: Stroked

Rod Length: 5.700 in.

Piston Style: Dish, with two valve reliefs

Piston Material: Forged aluminum

Compression Height (in.): 1.425 in.

Piston Head Volume (cc): +31.00cc

Wrist Pin Style: Press-fit or floating

Wrist Pin Retainers Included: Yes

Wrist Pin Included: Yes

Pin Diameter (in.): 0.927 in.

Piston Ring Thickness: 1/16 in. x 1/16 in. x 3/16 in.

File Fit: No

Gapless: No

Remanufactured: No

Quantity: Sold as a set of 8.

Notes: 0.310 inch deep valve pockets.
